Name: Enjoybot 36V LiFePO4 Lithium Trolling Motor Battery Set - 3 batteries
Brand: Enjoybot
SKU: EB-12100MINI-SHBT*3
Price: 61795 USD
Availability: InStock

TECH SPECS
FEATURES
FAQ
REVIEWS

Specification Comparison

Lithium Battery Pack	Capacity	Feature	BMS	Battery Size	Weight	Max. Discharge Current
	100AH, 1280WH	Low-Temp Protection	100A	Group 31 12.95 x 6.77 x 8.42 inch (per module)	69 lbs (32.4 kg)	100A Continuous Discharge 350A (3-5s) Peak Discharge Current
	100AH, 1280WH	Self-Heating	100A	Group 24 10.23 x 6.61 x 8.22 inch (per module)	66 lbs (30 kg)	100A Continuous Discharge 350A (3-5s) Peak Discharge Current
	150AH, 1920WH	Self-Heating, Bluetooth	150A	Group 31 12.95 x 6.77 x 8.42 inch (per module)	94.8 lbs (43 kg)	150A Continuous Discharge 500A (3-5s) Peak Discharge Current

Capacity: 100AH, 1280WH

Feature: Low-Temp Protection

BMS: 100A

Battery Size: Group 31
12.95 x 6.77 x 8.42 inch
(per module)

Weight: 69 lbs (32.4 kg)

Max. Discharging Current:
100A Continuous Discharge
350A (3-5s) Peak Discharge Current

Capacity: 100AH, 1280WH

Feature: Self-Heating

BMS: 100A

Battery Size: Group 24
10.23 x 6.61 x 8.22 inch
(per module)

Weight: 66 lbs (30 kg)

Max. Discharging Current:
100A Continuous Discharge
350A (3-5s) Peak Discharge Current

Capacity: 150AH, 1920WH

Feature: Self-Heating, Bluetooth

BMS: 150A

Battery Size: Group 31
12.95 x 6.77 x 8.42 inch
(per module)

Weight: 94.8 lbs (43 kg)

Max. Discharging Current:
150A Continuous Discharge
500A (3-5s) Peak Discharge Current

FAQ

A: Delivery within the continental U.S. typically takes between 2-7 business days, depending on your location.

A: The main difference between a Group 24 and Group 31 battery is their physical size.
Group 24 batteries are smaller, typically measuring 10.5" L x 6.19" W x 8.88" H. They are ideal for lighter-duty applications like small boats, RVs, and backup power systems.
Group 31 batteries are larger and provide higher capacity, making them suitable for heavier-duty applications such as larger boats, commercial vehicles, and high-demand RVs.

A: A self-heating lithium battery can be beneficial if you plan to charge your battery in cold environments. The self-heating feature ensures that the battery will charge properly in temperatures as low as 32°F (0°C). If you live in a region with cold winters or expect to use your battery in freezing conditions, a self-heating battery may be what you are looking for.

A: When the temperature drops below 32°F (0°C), charging is automatically suspended, and the built-in heating pad activates to warm the battery. At this time, the charger powers only the heating pad, ensuring safe operation. Once the temperature reaches 41°F (5°C), heating stops, and charging resumes, ensuring optimal battery performance in cold conditions.

A：These two features address the challenge of charging LiFePO4 lithium batteries in cold weather.

Low temperature protection automatically shuts off charging when the temperature drops below 32°F (0°C). To resume charging, simply place the battery in a warmer environment, and charging will be restored once the temperature rises to 41°F (5°C).

Self-heating enables charging at low temperatures by activating the heating mode when the temperature falls below 32°F (0°C). Charging will resume automatically once the battery reaches an optimal temperature.

A: Enjoybot 24V lithium battery set is compatible with 36V trolling motors offering 100-120 lbs of thrust

A: The charging range for the 36V battery pack is 42.6V to 43.8V. We offer both a 43.8V 12A charger and a 43.8V 20A charger for your choice. Additionally, to regularly balance the battery pack voltage, you may need a separate 14.6V 20A charger for charging each individual 12V battery.

Questions & Answers

Have a Question?

Ask a Question

Does the 20A charger charge all 3- batteries at once, or do you have to charge each battery separately ??

If you connect 3 12V batteries in series to get a 36V battery pack, then use this 43.8V 20A charger to charge the entire battery pack.
But this charger cannot be used to charge a single 12V battery because the voltage is too high and will damage the battery.
